meTering
Skid+prover+RTU

All cUSTODY
tRANSFER SOLUTION WITH CONFIDENCE

factory-tested and quality-approved before shipment.

• LPG (Liquefied Petroleum Gas).

• • Sulfuric Acid.

• • Crude Oil.

• • LNG (Liquefied Natural Gas).

• • Diesel.

• • Aviation and Jet Fuels.

• • High-Concentrate Hydrogen Peroxide.

LIQUID METERING
SKID

Meter Skid Specifications

• - Type of flow meter (e.g., Coriolis, ultrasonic, turbine).

  - Components of the skid:

  - Flow meter.

  - Valves.

  - Strainers or filters.

  - Pressure and temperature transmitters.

  - Flow computer or controller.

  - Material selection for piping and components

• Compliance and Standards

  - Industry standards (e.g., API, ISO, OIML).

  - Regulatory requirements for custody transfer.

  - Calibration and certification procedures

• Integration and Compatibility

  - Compatibility with existing systems (e.g., SCADA, DCS).

  - Communication protocols (e.g., Modbus, HART).

  - Electrical and power requirements.

gAS
METERING SKID

Design and Configuration

• - Type of meter (e.g., ultrasonic, turbine, coriolis).

• - Skid layout and dimensions.

• - Integration with existing infrastructure.

Materials and Components

• - Description of key components (e.g., flow meters, valves, transmitters).

- Material selection for durability and compatibility with gas type.

Automation and Control

• - Integration with SCADA or control systems.

• - Data acquisition and reporting features.

• - Communication protocols and remote monitoring capabilities.

“cUSTOMER eNGINEERED prover solution”

Benefits of Using Custody Transfer Prover Skids

• The use of custody transfer prover skids offers several benefits to industries requiring accurate fluid measurement:

  - Accuracy and Reliability: These systems provide highly precise calibration of flow meters, ensuring that measurements meet international standards.

  - Cost Savings: By reducing errors in fluid measurement, prover skids help prevent financial losses associated with inaccurate billing or product discrepancies.

  - Regulatory Compliance: Prover skids ensure that measurement systems comply with industry regulations and standards such as API (American Petroleum Institute) and ISO (International Organization for Standardization).

  - Ease of Use: The skid-mounted design allows for easy transportation, installation, and operation, making them suitable for both permanent and temporary setups.

  - Enhanced Efficiency: Automated control systems integrated into modern prover skids streamline the calibration process, saving time and labor.

“wE EMPOWER CUSTODY TRANSFER OPERATION THROUGH INNOVATIONn”
